Custom Low Voltage Switchgear Power Distribution Cabinet

The XL(F)-21 Low Voltage Switchgear Power Distribution Cabinet is a robust and reliable solution designed for power distribution in industrial, commercial, and utility applications. Suitable for three-phase three-wire, three-phase four-wire, and three-phase five-wire systems with AC voltages up to 500V, this cabinet is widely used in power plants, industrial facilities, and mining operations for efficient power lighting distribution.

Operating Conditions
The XL(F)-21 is designed to perform reliably under the following environmental and installation conditions:

Temperature Range: Operates effectively in ambient temperatures from -50°C to +40°C, with a 24-hour average not exceeding +36°C.

Altitude: Suitable for installations at altitudes up to 2,000 meters above sea level, maintaining consistent performance without derating.

Humidity Tolerance: Handles relative humidity up to 50% at +40°C, with allowances for higher humidity (e.g., 90% at +20°C) provided condensation is managed.

Installation Requirements: The cabinet must be mounted vertically, with a maximum tilt of 5° from the vertical axis. It should be installed in locations free from excessive vibration, mechanical shock, or corrosive agents to ensure long-term reliability.

Structural Design & Safety
The XL(F)-21 features a durable construction combining welded angle steel and precision-bent steel plates, providing structural rigidity and resistance to mechanical stress. The front door houses user interface components such as indicators and controls, while internal components remain fully accessible for maintenance.

Safety is prioritized through a welded grounding screw system, ensuring a low-resistance connection between the cabinet body and the earth. The inclusion of circuit breakers and isolators enhances protection against overloads and short circuits, safeguarding both equipment and personnel.
